OP-4600 Handheld 2D Barcode Scanner

Light source

White LED

Sighting device

Red LED, 167nm

Indicator light

Green for decoding success; red for decoding failure

Interface

KB;USB

Scanning speed

150scans/sec

Scanning type


Scanning angle

Elevation angle±70°, inclination angle±60°,rotation angle±180°

Recognizable printing contrast

Minimum 30% contrast

Decoding capacity

Standard 1D and 2D barcodes

Volume(L*W*H)

165mm*70mm*98mm

Weight

165g

Input voltage

4-5.5V DC

Operating power

2W; 400mA @ 5V –typical value

Standby power

0.45W; 90mA @ 5V –typical value

DC power supply

Class 2; 5.2VDC@1A

EMC

EN55022, EN55024, class B

LED safety certificate

IEC62471

CB

IEC60950

Certificate

GOST-R, CE

Working temperature

0℃-40℃

Storage temperature

-40℃-60℃

Humidity

5%-95% relative humidity, not condensation state

Illumination

0-100,000LUX

Shock resistance

Can bear the shock dropping from 2 meters height to the concrete surface

Dust proof

Seal up to prevent dust

IP level

IP52

Barcode density

Depth of scanning field

5 mil Code39

33-95mm (1.3-3.7 in.)

13 mil UPC-A

32-255mm (1.3-10.0 in.)

20 mil Code39

35-355mm (1.4-14.0 in.)

6.7 mil PDF417

30-95mm (1.2-3.7 in.)

10 mil Data Matrix

30-100mm (1.2-3.9 in.)

15 mil Data Matrix

21-162mm (0.8-6.4 in.)

20 mil QR

23-200mm (0.9-7.9 in.)

Resolution

4mil

Tolerance

100mm/sec 13mil UPC
