Barcode Scanner

  • OPT-9800 Desktop 1D Image Barcode Scanner
OPT-9800 Desktop 1D Image Barcode Scanner

OPT-9800 Desktop 1D Image Barcode Scanner

  • Product description: 32 bit ARM MCU+DSP
  • INQUIRY

Product Name: Desktop 1D Image Barcode Scanner

Model Number: OPT-9800


Physical Parameters

Material

ABS+PC

Size

L*W*H 150mm*143mm*82mm

Power Supply

DC 5V/2A

Weight

500±5g (without cable)

Performance Parameters

Support Interface

USB, USB virtual serial port

Sensor

Planar CMOS sensor

Light Source

Red LED (aim)+white LED (lighting)

Processor

32 bit ARM MCU+DSP

Decoding Capability

Codabar, Code39, Code32, InterLeaved 2 of 5 (14CHARS), Industrial 2 of 5, Matrix 2 of 5, Code93, Code128, Gs1-128, UPC-A, UPC-E, EAN/JAN-8, EAN/JAN-13, ISSN, GS1 DATABAR(RSS14), GS1 DATABAR Limited, Gs1databar Expanded

Resolution

Code39 3mil, PDF417 5mil, PCS45%

Depth of Field

5MIL CODE39: 3--11 CM

13MIL UPC-A : 4--27 CM

20MIL CODE39 : 7.5--35 CM

6.7MIL PDF417 : 3.5--9 CM

10MIL DATAMATRIX: 3--10 CM

15MIL DATAMATRIX: 3--17 CM

Scanning Speed

500scans/sec

Scanning Method

Auto-sensing

Scanning Area

5 * 5 cm² -- 30 * 30 cm²

Prompting Mode

Buzzer, indicator light(LED)

Printing Contrast

No lower than 35%

Scanning Angle

Roll 0-360°, pitch ±65°, yaw ±60°

Environment Parameters

IP Grade

IP 54

Operating Temperature

0 to 50 ºC / 32 to 122 ºF

Storage Temperature

0 to 50 ºC / 32 to 122 ºF

Operating Humidity

5 - 95% (non-condensing )

ESD Protection

15kv air discharge

Shock Resistance

1m free fall on concrete surface
