OP-9800 Desktop 2D Barcode Scanner

Light source

White LED

Sighting device

Red LED, 617nm

Indicator

Green=decoding successfully; red=fail to decode

Interface

KB, USB

Scanning type


Scanning angle

Angle of pitch ±70°，angle of inclination ±60°，rotation ±180°

Sensing distance

25cm (250cm2);20cm(100cm2);5cm(small area)

Sensing speed

200times/sec

Sensing delay

2sec/time

Discernible printing contrast

Minimum 30% contrast

Decoding capability

All standard 1D&2D bar codes

Size

110mm x 100mm x 150mm

Weight

120g

Input voltage

4 ~ 5.5 V DC

Operating power

2W; 400 mA @ 5V - typical

Standby power

0.45w，90mA@ 5V-typical

DC power

Class2;5.2VDC@1A

EMC

EN55022, EN55024 class B

LED safety certificate

IEC62471

CB

IEC60950

Other certificate

 CE, FCC, ROHS, FDA

Operating temperature

0°C - 40°C

Storage temperature

-40°C - 60°C

Humidity

5%-95% relative humidity (non-condensing)

Light level

0 - 100,000LUX

Shock resistance

Designed to withstand 2 meters drop on concrete surface

Dust proof

Seal to prevent air dust

IP level

IP40

Bar code density

Depth of field

5 mil Code39

33 - 95 mm (1.3 - 3.7 in.)

13 mil UPC-A

32 - 255 mm (1.3 - 10.0 in.)

20 mil Code 39

35 - 355 mm (1.4 - 14.0 in.)

6.7 mil PDF417

30 - 95 mm (1.2 - 3.7 in.)

10mil Data Matrix

30 - 100 mm (1.2 - 3.9 in.)

15mil Data Matrix

21 -162 mm (0.8 -6.4 in.)

20mil QR

23 -200 mm (0.9 -7.9 in.)

Resolution

4 mil

Tolerance

100mm/sec 13 mil UPC

Technical parameters are subject to be changed without notice!
