Thermal Printer

  • 58mm Thermal Receipt Printer
  • 58mm Thermal Receipt Printer
  • 58mm Thermal Receipt Printer
58mm Thermal Receipt Printer58mm Thermal Receipt Printer58mm Thermal Receipt Printer

58mm Thermal Receipt Printer

  • Product description: Application:Shopping malls, restaurants, stores, warehousing, taxation, banking, medical, postal
  • INQUIRY


Product performance:

Appearance compact design, fashion technology;

●Easy paper feed structure, simple and convenient operation;

●High reliability of large motor and large gear movement;

130 mm / second ultra high speed print, significantly improve the printing efficiency;

●Big paper warehouse design, the perfect support for 83MM large diameter rolls;

●Rich interface optional: USB, COM, Internet (100M), WIFI, Bluetooth, GPRS;

Support GB18030 large font and multi language ;

Supports LOGO and graphics downloads and print;

Supports Windows, Linux, Android and IOS system print;

100M Ethernet interface, print quickly while avoiding losing bills.

Application:

Shopping malls, restaurants, stores, warehousing, taxation, banking, medical, postal


Printer Parameters:

Items

Parameters

Print parameters

Printing

Method

Thermal Line

Printing Method

48MM

Resolution

384dots/Line(8dots/mm,203dpi)

Printing

Speed

130mm/Second

Interface

Type

USBCOMInternet100M),WIFIGPRSBluetooth

Line

Spacing

3.75 mm(Can adjust line spacing by command)

Line No.

Font A:32 character /Line

Font B:42 character/Line

Simple,traditional Chinese-16 lines

Character

Standard GB18030 simplified / traditional Chinese Fonts

Character

Size

ANKcharacter Font A 1.5 × 3.0mm 12 × 24

Font B:1.1×2.1mm(9×17 点) Simplified/Traditional Chinese:3.0×3.0mm(24×24 Dots)



Buffer

Input

Buffer

4K

NV Flash

40K

physical characteris tics

Weight

750g

Dimension

180*115*127(MM)

Environment

Working

Temp:5 ~ 45℃, Humidity:10 ~ 80%

Storage

Temp:-10 ~ 50℃ ,Humidity:10 ~ 90%(No dew)

Reliability

parameter

Print Head

Life

100KM(print density≤12.5)

Software

Driver

Android,IOS,Linux,,WinXP,Win7,Win8,Win8.1,Win10
