OP-520

Model

OP-520

Physical Parameters

Material

ABS+PC

Size

L*W*H：185mm*67mm*54mm

Power Supply

DC 5V ±5%

Operating Current

50mA（working）；30mA（sleep）；100mA（MAX）

Quiescent Current

20mA

Weight

130±5g（including cable）

Performance Parameters

Support interface

USB，RS232、PS/2

CPU

32bit ARM

Transmission rate

RS232 baudrate: 1200-115200

Light source

Visiable Laser 650nm （accord with national level laser safety standards）

Decoding capacity

Codabar， Code 93，Code128，UCC/EAN-128，Code 39，EAN-8，EAN-13，UPC-A，ISBN，Industrial 25，Standard 25，2/5 Matrix,ect.

Trigger mode

Trigger buttons, Automatic successive scanning, Automatic continuous  scanning

Sensing distance

15cm(100cm2)

Resolution

Minimum 3mils

Depth of scanning field

2—9cm（0.1mm bar width）；3—50cm（0.3mm bar width）

Decoding Speed

300times/sec

Bar width

5cm―30cm

Prompting Mode

Buzzer, indicator light

Printing Contrast

30%

Scan Angles

roll30°, pitch75°, yaw65°

Cylinder Horizontal Scanning

diameter 35mm

User Environment

IP grade

IP 54

Operating Temperature

0 to 50 ºC / 32 to 122 ºF

Storage Temperature

0 to 50 ºC / 32 to 122 ºF

Operating Humidity

20 - 85% (non-condensing)

Storage Humidity

20 - 85% (non-condensing)

ESD protection

15kv air discharge

Shock Resistance

1.5m free fall on concrete surface
