Barcode Scanner

  • OP-660 Bluetooth Barcode Scanner
  • OP-660 Bluetooth Barcode Scanner
  • OP-660 Bluetooth Barcode Scanner
OP-660 Bluetooth Barcode ScannerOP-660 Bluetooth Barcode ScannerOP-660 Bluetooth Barcode Scanner

OP-660 Bluetooth Barcode Scanner

  • Product description: Fully support connecting with any Bluetooth 2.0 device without using an external adapter.
  • INQUIRY

Product Name: Bluetooth Barcode Scanner

Model NO. : OP-660

Characteristics

(1)   Support Windows +Android+ IOS systems and suitable for smartphones, Tablet PC, Laptops and Desktops.


(2)   Fully support connecting with any Bluetooth 2.0 device without using an external adapter.


(3)   Excellent power management solutions. The optical parts oscillate only when the scanner is in reading condition and that effectively extend the service life of the scanner.


(4)   The transmission power is only 1 mW which will not have radiation to the human body.


(5)   With infrared induction function (optional)


(6)   750mA long lasting lithium battery inside


(7)   Have many scanning modes like continuous scanning, manual trigger, multiscan and auto switch off.

(8)   Built-in 64 KB memorizer can store about 3500 bar codes under inventory mode. (customizable)

(9)   Built-in 2 KB memorizer can store 110 bar codes in case Bluetooth connection interruption occurs.

Technical Parameters

Model No.

OP-660

PHYSICAL CHARACTERISTICS

Material

ABS+TPE+PC

Size

L*W*H:170mm*95mm*70mm

Color

White, Black

Power Supply

Built-in rechargeable 3.7V 750mA lithium battery

Accessories

Lithium battery, Charger, Bluetooth adapter

Weight

139g (With battery)

PERFORMANCE CHARACTIESTICS

Radio Range

10m Visual range

Module

Bluetooth class 2.0,Version+EDR

Interface Supported

USB

Communicate Mode

SPP

Light Source(Laser)

Laser LED 650± 20nm (national class I laser safety standard)

Decode Capability

Codabar, Code 11,Code 93,MSI,Code128,UCC/EAN-128,Code 39,EAN-8,EAN-13,UPC-A,ISBN,Industrial 25,Standard 25,2/5 Matrix, etc.

Resolution

Min 0.1mm(4mils)

Depth of Field

3—9cm(0.1mm bar width);3.5—45cm(0.3mm bar width)

Decoding Speed

100 times/sec

Scan Width

5cm―30cm

Prompting Mode

Buzzer, Indicator light

Print Contrast

30%

Scan Angles

Roll 30°Pitch 75°Yaw65°

Cylinder Horizontal Scan

Diameter 35mm

USER ENVIRONMENT

Operating Temp.

0 to 50. °C / 32 to 122°F

Storage Temp.

0 to 50. °C / 32 to 122°F

Operating Humidity

20-85% ( non-condensing )

Storage Humidity

20-85% ( non-condensing )

Shock Resistance

1.5m free fall on concrete surface
